CARINA NORTH WEST CORNER WIDE FIELD REGION
EMISSION NEBULA REGION IN CARINA (THE KEEL)
(Image centered at: ra 11 h:08 m / dec - 36º 38')
CLICK THE IMAGE FOR A HIGH RESOLUTION VIEW
May 2025, Home Backyard in Martinez, Buenos Aires, Argentina
DATA
TYPE:
APPARENT DIAMETER: FOV approximately 5 x 3.5 degrees
DISTANCE: for RCW 54 approximately 2900 parsecs (pc), which is equivalent to about 9460 light-years.
IMAGE INFORMATION
INSTRUMENT: CANON EF 200 mm f2,8 L lens stoped at 4,5
CAMERA: QSI 583 WS
MOUNT: Sky-Wacher EQ6 with SX Lodestar camera
FILTERS: BAADER LRGB Set
SKY CONDITIONS: urban skies - Bortle 8
EXPOSURES: LHARGB (40,120,40,40,40)
OBJECT DESCRIPTION AND IMAGE SESSION
A wide field area of the north west corner of Carina (The Keel) Constellation. A vast variety of deep sky objects can be seen in this image. The frame is rotated 90 degrees mainly dominated by RCW54 nebula complex.
This enormous nebular region lies in the direction of the Car OB2 association and parts of it may be ionised by stars in that association. Australian astronomer Collin Stanley Gum splits this region into several distinct nebulae and the RCW catalogue itself splits the region into four sub nebulae, which are described separately as RCW 54a, 54b, 54c and 54d and indicated in the annotated image below
CARINA NORTH WEST CORNER WIDE FIELD REGION
ANNOTATED IMAGE
