NGC 7293

HELIX NEBULA (AQUARIUS)

 (Image Centred at ra 22h:29m / dec -20:50)

CLICK THE IMAGE FOR A HIGHER RESOLUTION VIEW

July 2015 - Complejo La Aldea, San Luis, Argentina

DATA

Type: Planetary Nebula

Apparent Magnitude: 7.3

Apparent Diameter: 17.5 arc minutes

Distance: 450 light years

IMAGE INFORMATION

OPTICS: 6" f5 Orion Optics Reflector with Televue Paracorr working at 5.75

CAMERA: QSI 583 WS

FILTERS: Baader LRGB

MOUNT: Sky Watcher NEQ6

SKY CONDITIONS: rural skies.

EXPOSURES: LHaRGB (40,60,30,30,30) HaRGB bin 2x2

OBJECT DESCRIPTION AND IMAGE SESSION

NGC 7293 is one of the closest of all Planetary Nebula and also one of the mayor in apparent size. At the distance of 450 light years it offers a dramatic view of the final evolution stage of a Solar type star. Unfortunately it is not an easy object to observe. This is because the light spans over an important area a bit more of the size of half Moon. The nebula itself is 2.5 light year across. Even the Herschel’s could not catalogue this object. The name know as Helix is because its shape appearance in the photographs.
