 VELA SUPERNOVA REMNANT

Vela

Object Centered at

 (ra: 8:29 / dec -44:28)







January 20th 2008, taken from Mercedes Buenos Aires Province



Stretched and Inverted Image








DATA

TYPE: Supernova Remnant in Vela

VISUAL MAGNITUDE: N/A

IMAGE FIELD OF VIEW: 97 x 72 arc minutes

DISTANCE: 800 light years



OBJECT DESCRIPTION



The picture shows part of this large Vela Supernova Remnant region. The filaments structures is the result of a massive star that exploded some 11.000 to 12.000 years ago. The outer layers of the stars expanded to the interstellar space forming the gas structures with high energy particles which is still visible today.



The object presents a huge relative size that gives the possibility to explore some other interesting areas.  Unfortunately due time constrains I had to quit the session without the Luminance channel



IMAGE INFORMATION

SCOPE: William Optics ZenithStar 66, WO 0.8 Compressor riding in a LXD 75 Mount

SKY CONDITIONS: rural skies, Seeing 3 arcs seconds, Transparency good. Windy night

CAMERA: Starlight Xpress SXVF H9 @f 4.8

FILTERS: Astronomik Ha, Type II, Atik Filter Wheel

IMAGE ACQUISITION: AstroArt 3.0, CCD Control Interface 3.72

EXPOSURES: HaRGB (50,20,20,20)

PROCESSED: Calibrated (no darks, no flats, no offsets) in ImagesPlus. Digital Development in ImagesPlus,  CCD Sharp, Photoshop CS






Stretched and Inverted Image

Resized
