NGC 3519

OPEN STAR CLUSTER IN CARINA (THE KEEL)

(Image centered at: ra 11 h:04 m / dec - 61º 22')









May - 2024, Home Backyard in Martinez, Buenos Aires, Argentina






DATA

TYPE: OPEN CLUSTER WITH NEBULOSITY

APPARENT DIAMETER: 8 arc minutes

APPARENT MAGNITUDE (V): 7.7

DISTANCE: 4,500 light years (1.4 parsecs)



IMAGE INFORMATION

INSTRUMENT: 6" ORION OPTICS UK (Ultra Grade Optics) w/Sky Watcher Coma Corrector (0.9x) working at at f4.5

CAMERA: QHY 183 MONO

MOUNT: VIXEN GDPX, OAG with Starlight Xpress Lodestar

FILTERS: BAADER LRGB Set Antlia HA 3nm filter

SKY CONDITIONS: urban skies - Bortle 8

EXPOSURES: LHARGB (60,90,30,30,30)



OBJECT DESCRIPTION AND IMAGE SESSION

NGC 3519 is a very loose open cluster between NGC 3576 complex and Carina Nebula, therefore the background contains patches of emission nebula. To the right we have RCW 54a and to the left we have structure coming from NGC 3579. There are not many images of NGC 3519 and this zone in RGB nor information with regards this open cluster. NGC 3519 was discovered by English polymath and mathematician John Herschel in March 1834 from Cape of Good Hope.
