NGC 6242

OPEN CLUSTER IN SCORPIUS

 (Image Centred at ra 16h:55m / dec -39:39)





CLICK TO SEE NGC 6242 IN A WIDE FIELD VIEW



September 2015 - Camping La Porteņa, San Antonio de Areco, Buenos Aires, Argentina




DATA

Type: Open Cluster

Apparent Magnitude: 6.4

Apparent diameter: 9 arc minutes

Distance: 3900 light years



IMAGE INFORMATION

OPTICS: 8" f5 Orion Optics Reflector with Televue Paracorr working at 5.75

CAMERA: QSI 583 WS

FILTERS: Baader LRGB

MOUNT: Sky Watcher NEQ6

SKY CONDITIONS: rural skies.

EXPOSURES: LHaRGB (60,30,30,30,30) Ha + RGB shots at bin 2x2



OBJECT DESCRIPTION AND IMAGE SESSION

Deep south in the constellation of Scorpius lies this open galactic cluster which is close to the galactic plane. It is located at one degree to the north from IC 4628 nebula complex. In fact, the nebulosity in the image background is part of the mentioned HII region.

The cluster is marked by a bright yellow star (spectral type K5) which happens to be in the foreground but it is closer to us at a distance of 1000 light years. The age of NGC 6242 is estimated in 50 million years which is quite mature for an open cluster of this type.

The cluster was first noted by one of the most modern explorers of the southern sky: French astronomer Nicolas-Louis de Lacaille on his journey to South Africa in 1751 - 1752






NGC 6242

LABELLED IMAGE WITH IC 4628 COMPLEX IN SCORPIUS
