NGC 6563 - PLANETARY NEBULA

SAGITTARIUS

 (ra: 18.12,43/ dec -33:52)

July 2009, Home Backyard in Martinez - Buenos Aires, Argentina

DATA

TYPE: Planetary Nebula

Magnitude: m_b 13.8 m_v 11

Apparent Diameter: 48 arc seconds

DISTANCE: info not available

IMAGE INFORMATION

SCOPE: Celestron C8 SCT working at f6 (roughly)

CAMERA: SXVF H9

GUIDING: William Optics Zenithstar 66 with WO 0.8 x fr/ff

IMAGE ACQUISITION: AstroArt 3.0 - Control Interface 3.72 plug in

FILTERS: Astronomik Type II - Astronomik Ha 6 nm - Atik Filter Wheel

SKY CONDITIONS: urban skies - transparency and seeing regular

EXPOSURES: LRGB (20,20,20,20)

PROCESSING: Images Plus Sigma Combined Calibration (no darks no flats no bias), Images Plus Deconvolution, Photoshop CS2

OBJECT DESCRIPTION AND IMAGE SESSION

A faint and small planetary nebula in the constellation of Sagittarius located almost at the middle distance of Gamma and Eta Sagittarii. this object can be seen with a telescope at 87x with adverted vision. Larger apertures (8 to 10 inches) could detect its round shape and with the help of narrowband filters the thin arc at the limb can be visualized.

Moon was almost at full phase however I was impressed by the background stars capture by the C8 considering also that the transparency was not very good

(*) Sue French S&T July 2009 edition
