ABELL 13 (AKA PK 204-8.1)

PLANETARY NEBULA IN ORION

(Image centered at: ra 06:06 / dec + 03:57)





CLICK THE IMAGE FOR A LARGE VIEW



 December 2022 - February  2022, Home Backyard Martinez, Buenos Aires & Sarandí, Gualeguaychú - Entre Rios, Argentina






DATA

TYPE: Planetary Nebula

VISUAL BRIGHTNESS: 15,3

APPARENT SIZE: 2,9 x 2,2 arc minutes

DISTANCE: 3500 light years



IMAGE INFORMATION

SCOPE: 8" NEWTONIAN ORION OPTICS UK (Ultra Grade Optics) w/Televue Paracorr working at at f5,75

CAMERA: QSI 583 WS

MOUNT: SKY WATCHER NEQ6

FILTERS: Baader LRGB Set, Astronomik Ha 6mn

SKY CONDITIONS: Semi - urban Skies

EXPOSURES: LHaRGB (40,60,40,40,40) RGB binned 2x2



OBJECT DESCRIPTION AND IMAGE SESSION



Abell 13 is a relative large but quite dim planetary nebula in the constellation of Orion. It has an outer ring that stands out from it internal structure. It has an oval shape. The reddish color is quite noticeable and contrasts the dusty background environment.

The Abell catalog was published in 1966 by American educator George O. Abell and was composed by 86 entries of Planetary Nebulae collected by Robert George Harrington and Rudolph Mincowski

I stared imaging this object one year ago from a Bortle 4 skies focusing on the LRGB channels. The Ha integration was done from my home backyard in Bortle 8 skies in December 2022.
